Brand
|
OEM / SysePOS
|
|||
|
Model
|
518D
|
|||
|
Material
|
Aluminum base & ABS plastic screen
|
|||
|
Solutions
|
A
|
B
|
C
|
|
|
System Configurations
|
CPU processor
|
Intel® Celeron™ J1800 Dual-Core 2.41GHz Fanless
|
Intel® Celeron™ J1900 Quad-Core 2.0GHz Fanless
|
Intel® Core™ i3, i5, i7
|
|
Storage device
|
Mini SATA SSD 32GB, 64GB, 128GB or 2.5” HDD 500GB
|
|||
|
Memory
|
Single channel DDR3*1, 2GB up to 8GB
|
|||
|
OS support
|
Windows 10 Pro / Windows 10 IoT
|
|||
|
Display
|
Main display
|
17-inch LED display with 1280*1024 resolution
|
||
|
300:1 Contrast, 350cd/㎡ Brightness
|
||||
|
Touch panel
|
Capacitive touch screen
|
|||
|
I/O Interface
|
Serial
|
2
|
1
|
|
|
USB
|
5*USB type 2.0, 1*USB type 3.0
|
6*USB type 2.0
|
||
|
LPT
|
1
|
Not supported
|
||
|
HDMI
|
Not Supported
|
1
|
||
|
VGA
|
1
|
|||
|
DC
|
1
|
|||
|
LAN
|
1*10/100/1000Mbps Ethernet
|
|||
|
Audio
|
1*Mic-in, 1*Audio-out
|
|||
|
Options
|
Customer display
|
VFD type (2*20), Alphabet & Numeric
|
||
|
Second display
|
12.1-inch LED display / 15-inch LED display option
|
|||
|
MSR
|
Track 1&2&3
|
|||
|
Physical Dimension
|
Dimension
|
430*270*410mm
|
||
|
Weight
|
7.5kg
|
|||
|
Color
|
Black
|
|||
|
Environment
|
Power supply
|
DC 12V, 5A Adaptor
|
||
|
Temperature
|
Operating:-10℃ to 40℃, Storage:-20℃ to 60℃
|
|||
|
Humidity
|
Operating:20%-80%, Storage:20%-90%
|
|||
|
Certifications
|
CE, FCC, RoHS
|
|||
